STL STRIKER 8 - Wiring and Specifications; Wiring Diagram Details; Product Specifications

4 SpeedTech Lights, Inc © 2019
STRIKER
®
8
TRAFFIC ADVISOR
Specications
Voltage 12 VDC
Amps < 5.6
Optic TIR
LED Count Single Color: 32 / MultiColor: 64
Cable Length 12’ Light Bar Cable, 1.5’ Cig Plug Cable, 12.5’ AUX Cable
Flash Patterns 29 Warning Patterns, 13 Tra󰀩c Advisor Patterns
Wiring Diagram
Wire Color Function
Red (Thick)*
Positive
Black (Thick)*
Negative
Brown
Power
Yellow
Flash Pattern
Purple
Flash Mode
* Indicates a main power cable.
Wire Color Function
Green
Left Arrow
Orange
Center Out Arrow
Blue
Right Arrow
Grey
Slow / Fast
NOTE: All cables except Negative contact +12 VDC.
AUX Wiring Diagram
Wire Color Function
Red
AUX Positive
Blue
AUX Negative
