Hardware layout and configuration UM1932
10/30 UM1932 Rev 3
Figure 4. STM32F469I-DISCO top side layout
MSv38596V2
LD8
VBUS LED
LD1, LD2, LD3, LD4:
green, orange, red, blue
LEDs respectively
U1
Digital
microphone
ZZ1
4-inch DSI LCD
L
D
8
V
BUS LE
D
U6
Digital
microphone
SB17
Solder
bridge
SB18
Solder
bridge
U2
Digital
microphone
LD8
V
BUS
LED
