UM1932 Rev 3 25/30

UM1932 Hardware layout and configuration

4.19 ST-LINK/V2-1 USB Mini-B connector CN1

The USB connector CN1 is used to connect the embedded ST-LINK/V2-1 to the PC.

Figure 11. USB Mini-B connector CN1 (front view)

4.20 Audio jack CN3

A 3.5 mm stereo audio jack CN3 is available on STM32F469I-DISCO discovery board to

connect a headphone.

Table 12. USB Mini-B connector CN1

Pin number Description Pin number Description

1 VBUS (power) 4 GND

2 DM 5,6 Shield

3DP- -
