PRESENTATION AND INSTALLATION GUIDE – SN RANGE
APPENDIX D: EXTENSION MODULES (SN910/SN2000/SN3000/SN6000)
Inserting an extension module on SN910, SN2000 or SN3000 models
- Using the Power button on the front panel, or from the administration interface, proceed to shut
down the Firewall,
- Once it has fully shut down, ensure that you unplug it from any electrical power supply,
- Remove the filler panel by unscrewing the 2 knurled screws and extract it by pulling on both
screws,
- Present the module to be inserted, push it all the way in (push harder towards the end, then
screw in the 2 knurled screws,
- Reconnect the Firewall to the power supply,
- Using the Power button on the front panel, start the Firewall.
Extracting an extension module on SN910, SN2000 or SN3000 models
- Using the Power button on the front panel, or from the administration interface, proceed to shut
down the Firewall,
- Once it has fully shut down, ensure that you unplug it from any electrical power supply,
- Unscrew the 2 knurled screws and extract the extension module by pulling on both screws,
- Put back the filler panel by screwing in the 2 knurled screws,
- Reconnect the Firewall to the power supply,
- Using the Power button on the front panel, start the Firewall.
Inserting an extension module on SN6000 models
- Using the Power button on the front panel, or from the administration interface, proceed to shut
down the Firewall,
- Once it has fully shut down, ensure that you unplug it from any electrical power supply,
- Unlock and remove the empty module in place by lifting the small catch on the bottom left, while
pulling on both handles,
- Insert the extension module all the way in (until you hear a click to indicate that it has been
locked),
- Reconnect the Firewall to the power supply,
- Using the Power button on the front panel, start the Firewall.
Extracting an extension module on SN6000 models
- Using the Power button on the front panel, or from the administration interface, proceed to shut
down the Firewall,
- Once it has fully shut down, ensure that you unplug it from any electrical power supply,
- Unlock and remove the module in place by lifting the small catch on the bottom left, while pulling
on both handles,
- Put back the empty module to be inserted all the way in (until you hear a click to indicate that it
has been locked),
- Reconnect the Firewall to the power supply,
- Using the Power button on the front panel, start the Firewall.
