Fibre Channel Connections
4-4 Stratus ftServer 2600, 4500, and 6300 Systems: Site Planning Guide (R638)
Figure 4-1. Fibre Channel Connections to an ftScalable Storage System Using Switches
Figure 4-2. Direct-Attach Fibre Channel Connections to an ftScalable Storage System
Fibre Channel Switch 2 Fibre Channel Switch 1
ftScalable Storage
RAID Controller Tray 2
ftScalable Storage
RAID Controller Tray 1
CPU Element 0
I/O Element 10
CPU Element 1
I/O Element 11
dco048
ftScalable Storage
RAID Controller Tray 1
ftScalable Storage
RAID Controller Tray 2
CPU Element 0
I/O Element 10
CPU Element 1
I/O Element 11
dco047
