System Specifications A-1
Appendix A
System Specifications
A-
For system specifications, see:
“System Specifications” on page A-1
“PCI Adapter Specifications” on page A-7
“AAP87600 PDU Specifications” on page A-8
1. The system temperature and humidity requirements
defined in Tables A-2 are the minimum requirements
the site must provide.
2. The temperature and humidity requirements for
optional components are provided in the Stratus
ftServer Systems: Peripherals Site
Planning Guide (R582).
System Specifications
The following figures show front and rear views of the systems.
Figure A-1 shows the front of an ftServer 2600, 4500, or 6300 system, mounted in
a rack with its bezel pulled forward.
Figure A-2 shows the rear of a rack-mountable ftServer 2600, 4500, or 6300
system, specifying the locations of the connectors at the rear of the system.
Table A- 1 lists the dimensions of the system cabinets supplied by Stratus. Tab l e A-2
lists the specifications for each ftServer CPU- I O enclosure, the front panel, and the
backplane assembly. Tab le A- 4 lists the specifications of the PDU. See the Stratus
ftServer Systems: Peripherals Site Planning Guide (R582) for the specifications of
other components.
