Remedying Faults in PP 1207–Klöckner Möller
Remedying faults PP 1207
page 25 –April 2005
D. Klöckner Möller safety relay
D. ABB safety relayIf sensors and evaluation unit are OK, the relay
(K1.12 ABB, K2 KLM) must rise and switch on. Check
relay terminals A1 and A2 for voltage and change
relay if necessary.
2.3 Machine does not start
D. Relay faulty
