Strobel 310D-R - Page 36

258.21.66en
Electrical connection plan cl. 300
(DC1200-AB611A)
Control box Efka drive
(1) Nominal voltage 24V, idle voltage max. 30V
Designation
Strobel operating manual
Designation
Efka operating manual
PIN
37 pin
Sub-D
Colour code
connection cable
Lifting (LÜ) Press foot lifting (FL) 35
17
White
brown
ST2
+5V / 0,2A
0V
+15V / 0,3A
+24V(1)
+24V(1)
+24V(1)
0V
POS1Q
POS2Q
G1Q
3A
+24V(1)
+24V(1)
3A
0,5A
0,5A
0,5A
6,5A
6,5A
3A
3A
0,5A
0,5A
0,5A
0,5A
LÜ ( MV1 )
