Setup and installation
Strobel machines are supplied either as complete units with head, stand and
motor, or head with motor only, or the head only.
Unpacking the machine
Reel stand, rods and other accessories are packed into the packing.
Make sure that all accessories have been unpacked before throwing away any
packing material.
3.2 Setting up the machine
CAUTION! Danger of injury!
Entanglement hazard for clothing or hair and
Danger of finger injuries!
Never operate the machine without the belt guards for the
upper part and motor.
If the machine head is supplied without stand and motor first make the borings
into the table top as shown in the drawing. Mount rods and treadles and electric
connections according to the connecting diagram.
Mount the motor. Electric connection as per connecting diagram shown in the
motor's operating instructions.
The upper component must be fastened to the provided rubber plate on the
table top. The belt guard must be installed after inserting the V-belt.
Mount the V-belt and tense it according to “3.4.1 Tensioning the V-belt“.
Mount the belt guard.
Mount the lifting and motor operating rods.
Using a compact motor means to assemble the control box and speed controller
under the table. Also the operating rod between speed controller and pedal has
to be connected.
After assembling the single parts of the reel stand mount it to the right hand side
of the tabletop.
Make sure that all screws on the stand are tight and retighten them, if
necessary.
Mount the synchronizer and set it as described under “3.4.2 Positions of the
machine“.
