Strobel VEB100-1 - Sewing with Folder

32 BA_VEB100-1-2-2W-4-5_A3-1_180615_en
Fig. 11
Fig. 12
5.3.2
Folder (Cl.VEB100-5)
Sewing with folder
The machine is equipped with a special combination of needle plate and folder
to provide side and back parts of sack coats with a uniform book seam.
Folders with a width of 6, 8 and 10 mm (finished hem width after pressing) are
available.
The standard machine is equipped with folder 286.0364, size 6x1 for thin to
medium material.
Roll seamer (Cl. VEB100-4)
The needle plate is equipped with a special material guide (roll seamer) that
"rolls in" the sewing material at the edge during the running into the needle plate.
The roll seamers No. 0, 1, 2, roll diameter are available for thin medium, thick
material and and the Special roll hemmer for sewing curves.
Serially, the standard roll seamer 286.0428, size 1, has been mounted and set
for medium sewing material.
