Strobel VEB100-1 - Replacing the Folder; Hemming with Folder (Cl.veb100-5)

35 BA_VEB100-1-2-2W-4-5_A3-1_180615_en
Fig. 14
a b
Cl. VEB100-5 Cl. VEB100-4
Fig. 15
a b c
5.3.2.2
Loosen screw (4) (
Replacing the folder
Fig. 14), mount and tighten the new folder.
Realise settings as described in “5.3.2.1 Setting the folder“.
5.3.2.3
When the material support arm is lifted place the material from the left side and
push the folded corner under the feed dog's front edge. The machine should be
switched on and should have positioned at least one time (stop motor). The
seam starts approx. 1 stitch length behind the fabric edge. When using the
standard 6 mm folder a stitch length of 7 mm is recommended.
Hemming with folder (Cl.VEB100-5)
During the hemming operation the hem edge should always run along the upper
folder edge. As a guide serves opening (5) in (Fig. 14).
