Strobel VEB100-1 - Seaming with Roll Seamer (Cl. VEB100-4)

36 BA_VEB100-1-2-2W-4-5_A3-1_180615_en
5.3.2.4
The machine should be switch on and have positioned at least once (stop
motor).
Seaming with roll seamer (Cl. VEB100-4)
The sewing material is inserted into the roll seamer from the left side whilst the
material support arm is lifted. Pull the material diagonally forwards to under the
feed dog. A rolling should be done thereby manually in the roll seam nozzle.
Pull back the sewing material so that the feed dog can catch it. Close the
material support arm. The beginning of the stitch is then about 1 stitch length
behind the edge of the material.
During the sewing, the seam edge needs to be guided by hand evenly along the
seamer infeed (3) Fig. 14b.
Of advantage is to turn the material counter-clockwise (Fig. 16) during the
sewing.
Fig. 16
