1. Power indicator /remote sensor
2. Speakers
3. Buttons: V-/V+, CH-/CH+.
4. Combo button; Input source, Menu, Standby/ON.
2.3 Rear panel
NOTE: The graphics are for representation only.
Fig.3
1. AC INPUT (FIXED CABLE)
Main power cable (180 - 240 V ~ 50/60 Hz)
2. Vesa 100 x 100 4 x screws holes to mount TV to wall.
NOTE: The graphics are for representation only.
Fig. 3a
1. Channel up/down button
2. Volume up/down button
3. q/Menu Press to turn the TV on or standby/Enter Menu
2.4 Side panel
NOTE: The graphics are for representation only.
Fig. 3b
1. COMMONINTERFACE (CI)
Connect a Conditional Access Module (CAM).
2. USB Connect a USB device for playback of multimedia les
3. EARPHONE Speakers will be muted when earphone is plugged in and headphone
selected.
4. AV IN 3.5 mm female jack entry for composite video and left/right audio
connection.
5. HDMI 1 Connect HDMI input signal from a signal source such as DVD, Blu-ray player
or game console.
6. HDMI 2 Connect HDMI input signal from a signal source such as DVD, Blu-ray player
or game console.
7. SATELLITE IN Connect a satellite dish to the TV for searching programmes.
8. ANTENNA IN Connect a terrestrial antenna or cable connection from your provider to the
TV for searching programmes.
9. S/PDIF Use an RCA cable to connect your TV to a compatible digital ampli er or
Home theatre set.
5
English
