109
How to Connect
Connect the TV antenna to TV ANT IN
Connect the Video and Audio of the TV to Video and Audio: connect the red
and white connectors to Audio R and Audio L, and the yellow connector to
Video
Connect your satellite dish
3
2
1
When Connecting the Receiver to a TV
Operation
6.1 Getting Started
<Figure 6.1.1>
After your receiver is powered on, proceed with installation as follows :
1) Menu Language Setting
⊹
Turn on your TV and receiver.
⊺
The pop-up menu for language selection will apprear. <Figure 6.1.1>
Select one language and press button to proceed.
2) Antenna Setup
⊹
Press the button to display the main menu.
⊺
Use / button and / button to move in the menu.
⊻
Press button on “Dish Setting”. The following window will aprrear. <Figure 6.1.2>
If you have a motorized dish, press button on “Motorized Setting”. <Figure 6.1.3>
To Next Page
