96 1 U701
Digital DVB-T/T2 Demodulator：MSB1230 - LF，64-pin LQFP
97 1 U201 Capless 2Vrms to 3Vrms Line Driver with Adjustable Gain:SGM8905 MSOP-10
98 1 U401 DVB-T/C HD STB System-on-Chip:MSD5043-I00,BGA-417
99 1 J601
HDMI 座: 51U019S-301N-A-B*//161A0012 ，19PIN，Pitch=0.5mm
100 1 PCB
DTT1609MB 2011-12-20 167.5*(117.5*2)MM (双面板)
Item Q'ty Location Remark
1 1 L902
IND-MOLDED,4.7UH Ferrite DR2W6*8.3-4.7UH／4.7uH DR2W6*8
2 1 L132
IND-MOLDED,22uH Ferrite 3A DR2W9*12-220K-PVC／22uh DR2W9*12
3 3 CE171 CE172 CE402 C-AL ; 47uF, 20%, 25V-5*11*5, FORMING CUT TYPE
4 8 CE107 CE122 CE201 CE301 CE561 CE702 CE703 CE704 C-AL ; 100uF, 20%, 16V-5*11*5, FORMING CUT TYPE
5 3 CE132 CE142 CE152
C-Aluminum :220UF 16V 20% BARREL6.3*12*5.0 高频低阻
6 2 CE501 CE751 C-AL ; 470uF,20% ,16V, 8*12*5 FORMING CUT TYPE
7 1 C910
C-Aluminum : 10UF 400V 20% BARREL10*17*5 105℃高压电容
8 1 C911
C-Aluminum : 15UF 400V 105℃ 20% BARREL 13*16*5 高压电容
9 1 C912
C-AL ; 10uF, 20%, 50V-5*11*2.0
10 1 C916 C-AL ; 470uF,20% ,16V, 8*12*3.5MM FORMING CUT TYPE
11 1 CY902 Y1-CAP 1000PF 400V 20% BARREL 8*10*25
12 1 C913
4.7nF 1KV Y5U 10%
13 1 C915
C-Aluminum :1000UF 16V 20% BARREL10*16*5 高频低阻 供应商：金富康
14 4 D910 D911 D912 D913 DIODE-RECTIFIER ; 1N4007ID,1000V,1A,DO-41
15 2 D917 D919 SCHOTTKY BARRIER RECTIFIERS 1N5822 3.0A TO-27
16 1 U903 Regulator MOSFET:ZL431AZ-ATRE1 ,precision is 0.4% ,TO-92
17 1 U902 光耦: LTV-817-CN, 200~400%, DIP-4
18 1 U901 Power switch IC:TNY176PN DIP-8C
19 2 Y401 Y701
晶体：24.000MHZ,±20PPM，20pF，HC-49S DIP
20 1 LF902 Filter Transformer: LB1111-8496A,17*12*17mm,4Pin,Pin Length:3.5mm
21 1 T901
变压器：KB1025-17474 ，EE-19，5（二脚空缺）+5（六八十脚空缺） Pin，立式
22 1 F902
双冒绕丝保险管:3T 250V/1A, ф4×11mm
23 1 RT901
R-NTC: 10 OHM,20%,负温系数,黑色
24 1 CN902 CH-3x3.96 (NO Middle PIN)
25 1 CN401
2.54-4Z,TJC3-4A PITCH=2.54MM,4P,WITH LOCK
26 1 J301
AV4-8.4-33 WYRB 带屏蔽
27 1 J502
SMARTCARD：ICA-611 STF，Standoff H=17.10mm 常闭，10Pin
汉宝
28 1 J801 Single SCART Connector no shield cover SC103 21P
29 1 IR101 IC-REMOTE CONTROL ; HM338-WS 3PIN
30 1 FOR IR101
SUPPER :7MM
31 1 D122
4-digit 7-segment display：LIM-2483N25E 单排6mm+13mm 12pin 橙色共阴 黑面白胶
32 1 FOR D122
9mm SUPPORT
33 1 D191
3RG9HW M3/ LL-309IGM2E-I1-2A/AVL-313RGD-01,共阴(红绿双色)DIP
DIP
