3.2.2 Module Id. and Firmware Revision Register ( read)
#define SIS3153USB_MODID_VERSION 0x1
This register reflects the module identification of the SIS3153USB and its minor and major
firmware revision levels. The major revision level will be used to distinguish between
substantial design differences and experiment specific designs, while the minor revision level
will be used to mark user specific adaptations.
Bit
Function
Reading
31
Module Id. Bit 15
3
30
Module Id. Bit 14
29
Module Id. Bit 13
28
Module Id. Bit 12
27
Module Id. Bit 11
1
26
Module Id. Bit 10
25
Module Id. Bit 9
24
Module Id. Bit 8
23
Module Id. Bit 7
5
22
Module Id. Bit 6
21
Module Id. Bit 5
20
Module Id. Bit 4
19
Module Id. Bit 3
3
18
Module Id. Bit 2
17
Module Id. Bit 1
16
Module Id. Bit 0
15
Major Revision Bit 7
14
Major Revision Bit 6
13
Major Revision Bit 5
12
Major Revision Bit 4
11
Major Revision Bit 3
10
Major Revision Bit 2
9
Major Revision Bit 1
8
Major Revision Bit 0
7
Minor Revision Bit 7
6
Minor Revision Bit 6
5
Minor Revision Bit 5
4
Minor Revision Bit 4
3
Minor Revision Bit 3
2
Minor Revision Bit 2
1
Minor Revision Bit 1
0
Minor Revision Bit 0
Major revision number
Application/user
0x01
Generic SIS3153USB design (internal 32-bit interface support)
0x16
Generic SIS3153USB design (internal 16-bit interface support)
