SIS3153
VME interface
Page 28 of 38
7.4 JP123 LEMO input, JP133 LEMO output logic level
Example:
JP123 both inputs configured for NIM (i.e. at factory default setting)
JP133 both outputs configured for NIM (i.e. at factory default setting)
Note: The position for the jumpers for TTL is printed on the silk screen of the PCB.
