Structural Concepts CO47R - Optional Roll down Security Door (See Previous Page for Retracted Door)

Roll Down Security Door (Optional): Shown Extended
 Optional roll down security door has two handles for
grasping, lowering and raising.
 After door is lowered, key may be turned clockwise to lock
latch into strike bracket.
 Turn counter-clockwise to unlock.
 Keep keys in safe and secure place.
 See STIFFENER (FOR OPTIONAL ROLL DOWN
SECURITY DOOR): PURPOSE / REMOVABILITY section
on next page.
Latch
12
OPTIONAL ROLL DOWN SECURITY DOOR (SEE PREVIOUS PAGE FOR RETRACTED DOOR)
Lock
Keys
Strike Bracket
H
a
n
d
l
e
s
(
F
o
r
L
o
w
e
r
in
g
&
R
a
i
s
in
g
S
e
c
u
r
it
y
D
o
o
r
)
Illustration Shown Reflects Model CO65R.
Your Model May Vary in Length and Height.
