INSTALLATION, CONTINUED: ACRYLIC DIVIDER INSTALLATION (OPTIONAL)
7. Optional: Acrylic Divider Installation
(Self-Contained Cases Only)
The Acrylic Divider Kit contains the
Acrylic piece, 1/4-20 screws and
washers.
The Acrylic Divider is to be installed on
the Left Case (when facing cases).
When properly installed, it will be flush
with inside edge of left Case tab, to
allow for seamless adjoining of Cases.
Note: Enlarged views at right show
proper placement of Acrylic Divider.
Acrylic Divider’s
Obround Hole
(Mounted at Inside of
Left Case’s Tab)
Left Case
Right Case
Left
Case
Tab
Right
Case
Tab
Acrylic
Divider
Note:
Illustration
Shown May Not
Exactly Reflect
Every Feature
or Option of
Your Particular
Case
