MAINTENANCE FUNDAMENTALS: BALLAST ACCESS
Ballast Access
 Assembly or disassembly and servicing is to be accomplished by a licensed electrical contractor.
 Remove rear grille by lifting up and off.
 Ballast are mounted inside the electrical box.
 Illustrations shown reflect models CO37R and CO67R. Your model may slightly vary.
Rear View of Model CO67R
After Rear Grille Removed
Ballasts (In
Electrical Box)
Rear View of Model CO37R
After Rear Grille Removed
Ballasts (In
Electrical Box)
