1. Wall Spacing / Rear Venting (May
Not Be Applicable To Your Model)
• Caution: Venting is an integral part of
case temperature management. Do not
remove rear panel!
• Rear grille may be removed (by
removing 4 screws) for service or
maintenance of condenser unit.
• Return rear grille to case rear when
completed.
2. Caster Locking Operation
• Depending upon your case design,
casters may be locked and unlocked.
• To lock casters push down on lever, to
unlock pull up the lever all the way.
• See illustration below-left.
13
WALL SPACING / REAR VENTING / CASTER LOCKING OPERATION
Model BV4732 Shown Above
(Partially Disassembled For Illustrative Purposes Only)
Rear Panel (Shown Transparent
For Illustrative Purposes Only)
Rear Grille
Locked
Unlocked
--- Sample Caster Design ---
To Next Page
