SELF-CONTAINED HOT GAS LOOP CONDENSATE PACKAGE LAYOUTS - PAGE 1 of 3
1. Self-Contained Hot Gas Loop Condensate Package
• Caution: Only trained service providers are to provide maintenance and service to unit.
• Warning! Disconnect power before providing maintenance and service to unit.
• Note: Illustration shown may not reflect your particular condensate package layout.
Sight Glass
Filter Dryer
Embraco®
Starter Unit
Electrical Box
Overflow Pan
Hot Gas Condensate
Coils and Pan
Condenser Coil
Condenser Coil
Housing
Condenser Coil Fan &
Housing
Compressor
CleanSweep® Housing
