Hint
The maximum height of specimens in the specimen holder is 32 mm.
If the specimens exceed 32 mm, the specimen holder cannot be placed in the
specimen mover head.
1. Press the Lower/Raise button to make sure that the specimen mover head is
fully raised.
2. Press the black button on the specimen mover head.
3. Insert the specimen holder and rotate it until the three pins are aligned with the
holes in the specimen mover.
4. Push the specimen holder upwards until it locks into position.
5. Release the black button on the specimen mover head. Make sure that the
specimen holder is securely fixed.
5.6.2 Inserting a specimen mover plate
1. Press the Lower/Raise button to make sure that the specimen mover head is
fully raised.
2. Press the black button on the specimen mover head.
3. Insert the specimen mover plate and rotate it until the three pins are aligned with
the holes in the specimen mover.
4. Push the specimen mover plate upwards until it locks in position.
5. Release the black button on the specimen mover head.Make sure that the
specimen mover plate is securely fixed.
5.6.3 Adjusting the height of the specimen mover plate
The following applies only when specimen mover plates are used.
12 LaboForce-100
5 Installation
