30” Slider Board Assembly
120
Assembly part number 0785−045−310 (reference only)
Item Part No. Part Name Qty.
A 0023−288−000 Hex Washer Hd. Screw 4
B 0785−018−001 Slider Board 1
C 0785−045−311 30” Slider Board Tray 1
0785−018−001 Slider Board
37.5”
25.0”
