Stryker altrix - Rinsing the Internal Water Circuit and Hoses

8001-069-002 Rev B.2 Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 12A
1. Usingappropriatemeasuringequipment,lltheemptyreservoirwith
1gallons(3.8L)ofsterile-distilledwater.
2. Place the reservoir into the controller.
3. Connect the bottom hose end to the hydraulic connector in the lid of
thereservoir(Figure32).
4. Plugthepowercordintoawalloutlet.
5. PressandholdtheStand-bybutton.
6. TaptheManualmodeicon.
7. TapConrm.
8. Selectthewatertargettemperatureof25.0°C(77.0°F).
9. TapConrm.
10. Allowthecontrollertorunfor5minutes.
Note:Thetimerwillrunonthemain
display,followthecurrenttherapydurationtimer.
11. After5minutes,turnthecontrolleroffbypressingandholdingthe
Stand-bybuttonfortwoseconds.
12. Unplugthepowercordfromthewalloutlet.
13. Placethecontrolleroveraoordrain.
14. Removethereservoir.Pullforwardatanangle,andliftoutthereservoir.
15. Removethebottomhoseendfromthehydraulicconnectoradapterin
thereservoirlidbypushingdownonthecollar.
16. Emptywaterfromthereservoir,disposeofthewaterperhospital
protocol.
17. Pulluponthecontrollerdrainplugtoopenthedrain.
18. Makesurethatall3hosesremainraisedabovetheconnectionports
fordraining.
19. Allowthecontrollerandhosestodrainforaminimumoftwominutes.
20. Pushdownonthecontrollerdrainplugtoclosethedrain.
21. Wipetheinsideandoutsideofthereservoirandreservoirlid,withadry,
soft,lintfreecloth.
22. Place the reservoir into the controller.
23. Disconnectandstoretheservicetooladapterhosesfromallthreeofthe
hoses.(Ifapplicable,whenusedwithcolderstylehoses.)
24. Storethepowercord,cables,andhoses.
Rinsing the internal water circuit and hoses
Figure 32
