8001-069-002 Rev B.2 Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 4A
Manual therapy
InManualmode,theproductcontrolsthewatertemperatureonly.A
temperatureprobeisnotrequiredwhenoperatinginmanualmode.
Display the patient data graph
Todisplaythepatientdatagraph,tapthegraphicon.
Thepatientdatagraphstoresthefollowingvariables:
• Primarypatienttemperaturereading(A)
• Intermediatetargettemperature(B)
• Watertemperature(C)
• Powerlevel(D)
Pause therapy
• Topausetherapy,pressandholdthePauseTherapy
button for two seconds.
• Toresumetherapy,pressandholdthePauseTherapy
button for two seconds.
Stop therapy
• PressandholdtheStand-bybuttonfortwoseconds.
• Unplugtheproductfromthewalloutlet.
• Opentheclampsforapproximately10minutestoallow
the water to drain back into the controller.
• Closeclampstostopthewaterowanddetach
wrapsfromhoses.
A
B
C
D
Select Manual therapy mode
and conrm
Select desired water
temperature
