8001-069-002 Rev B.2 Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
card 3A
Initiation of therapy
Selecting a therapy mode
Youcanselectfromoneofthesethreemodes:
• Automatic(therapy)
• Manual(therapy)
• Monitor(non-therapy)
Automatic therapy
InAutomaticmode,thetherapycoolsorwarmsthepatienttoaselected
patienttargettemperature.Theproductcontinuallymeasuresthe
patienttemperatureandautomaticallyadjuststhewatertemperature
untiltheselectedpatienttargettemperatureisachieved.
Cooling
Warming
SelectAutomatictherapy
modeandconrm
PressEdit
SelectTargetTemperature
andconrm
SelectTargetTemperature
andconrm
SelectMax,Med,Min
andconrm
SelectMax,Med,Minor
Customandconrm
Quick start guide for
Altrix Precision Temperature Management System
