Stryker CORE 2 Console - Screens and Menu Tabs

5400-052-700-EN Rev-D EN
www.stryker.com 9
10 Screens and Menu Tabs
Preset
Console
System Settings
Select Motor
Rep Info
Control
Permissions
Import/Export
Irrigation
Motor 1
Motor 2
Motor 3
Home
Import
Volume
Brightness
Language
System Info
Export
Motor List
Motor Settings
General
Irrigation
Motor Options
Control Options
Quick Access
Figure 4 – Screens and Menu Tabs Map
