Controls and Indicators
2-2 LIFEPAK 1000 Defibrillator Operating Instructions
CONTROLS AND INDICATORS
This section introduces you to the controls and indicators on the LIFEPAK 1000 defibrillator.
Figure 2-1 Controls and Indicator
Table 2-1 Controls and Indicators
Feature Description
1 Readiness display The readiness display alerts you to the defibrillator’s readiness
status.
Three symbols ( , , ) allow you to determine whether the
defibrillator is ready for use or needs attention.
The following defines what each symbol represents and
when/where each appears.
The wrench indicator appears on the readiness display when a
condition exists that prevents or could prevent normal
defibrillator operation.
The OK symbol indicates that the defibrillator is ready for use.
It is visible only when the defibrillator is off.
The OK symbol will not appear if the battery is low or the
device requires service.
The battery symbol appears on the readiness display when the
defibrillator is off. When one bar is visible in the symbol, the
battery is low and should be replaced.
2 Speaker Provides audio voice prompts and tones.
(Left side)
1
3
4
6
98
10
2
5
7
(Left side)
9
