Stryker LIFEPAK 15 User Manual

Page 8
LIFEPAK 15 Monitor/Defibrillator
Features, left side,
Continuous temperature option
Connection Action
Connect: Open CO2 port door, insert FilterLine
connector, and turn clockwise until connector is
rmly seated.
Disconnect: Rotate FilterLine connector
counterclockwise and pull connector out.
Connect: Align cable connector with SpO
2 port
and push in until connector clicks into place.
Disconnect: Press the gray buttons on each side
of the cable connector simultaneously and pull
connector out.
Connect: Insert NIBP tubing connector into the
NIBP port.
Disconnect: Press the latch on the left side of the
port and pull tubing connector out.
Connect: The green ECG connector with the green
ECG port. Insert the cable connector into the port
until the connector is rmly seated.
Disconnect: Use the nger pull to pull the ECG
connector straight out.
Connect: Align the temperature adapter cable to
the temperature port. Attach selected temperature
sensor to adapter cable.
Disconnect: Grip the connector and pull straight out.

Stryker LIFEPAK 15 Specifications

General

Battery	Lithium-ion
Defibrillator	Yes, biphasic
Defibrillation Energy Range	1-360 J
SpO2 Monitoring	Yes
NIBP Monitoring	Yes
EtCO2 Monitoring	Yes
Invasive Pressure Monitoring	Yes
Temperature Monitoring	Yes
Connectivity	Bluetooth, WiFi
ECG Monitoring	12-lead
