Page 9
LIFEPAK 15 Monitor/Debrillator
Acquiring a 12-Lead ECG
1. Press 12-LEAD Button
2. AGE Menu – enter Age
3. SEX Menu – enter Sex
4. 12-Lead acquires, analyses
and automatically prints the
12-Lead ECG
Angle of
Louis
Lead Location
V1/C1 Fourth intercostal space to the
right of the sternum
V2/C2 Fourth intercostal space to the
left of the sternum
V3/C3 Directly between leads V2/C2
and V4/C4
V4/C4 Fifth intercostal space at
midclavicular line
V5/C5 Level with V4/C4 at left anterior
axillary line
V6/C6 Level with V5/C5 at left
midaxillary line
Main Cable
(4-wire)
Protective
ap (open)
Precordial lead
attachment

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Stryker LIFEPAK 15 and is the answer not in the manual?

Stryker LIFEPAK 15 Specifications

General IconGeneral
BatteryLithium-ion
DefibrillatorYes, biphasic
Defibrillation Energy Range1-360 J
SpO2 MonitoringYes
NIBP MonitoringYes
EtCO2 MonitoringYes
Invasive Pressure MonitoringYes
Temperature MonitoringYes
ConnectivityBluetooth, WiFi
ECG Monitoring12-lead
