pg 14
blueSky - reverberator
External Control
Expression Pedal Setup
Use a TRS expression pedal to control the knobs of blueSky�
1 Configure the EXP/MIDI jack for Expression mode� (See page 12 for
configuration instructions�)
2 Connect an expression pedal to the EXP/MIDI jack of blueSky using a
TRS cable�
RIGHT IN LEFT OUT RIGHT OUT EXP
MIDI IN
USB
MIDI OUT
3 Press and hold both footswitches until both LEDs blink GREEN�
4 Rock the expression pedal to the HEEL position� Only the FAV LED will
blink GREEN�
5 Set the knob(s) you would like to control to the desired settings for
the HEEL position of the expression pedal� Only the FAV LED will turn
RED�
6 Rock the expression pedal to the TOE position� Only the ON LED will
blink GREEN�
7 Set the knob(s) you would like to control to the desired settings for the
TOE position of the expression pedal� Only the ON LED will turn RED�
8 Press either footswitch to exit and store your expression pedal setup�
NOTE: Your expression pedal assignment is saved per Favorite setting or
MIDI preset�
NOTE: If blueSky is set to respond to MIDI EXPRESSION and the EXP/MIDI
jack is set to MIDI mode, you can send MIDI CC# 100 with values 0 (heel) to
127 (toe) to perform the expression pedal setup�
