pg 26
blueSky - reverberator
MIDI Specifications (cont.)
MIDI CCs
blueSky - MIDI CC NUMBERS
CC# PARAMETER RANGE ENUMERATION
0 Bank Select 0-2 (0=Bank 1, 1=Bank 2, 3=Bank 3)
11 Verb Type 1-3 (1=plate, 2=room, 3=spring)
12 Decay 0-127
13 Low 0-127
14 Pre-Delay 0-127
15 Mod Type 1-3 (1=off 1, 2=light, 3=deep)
16 Mix 0-127
17 High 0-127
18 Shimmer 0-127
60 MIDI Expression Off/On 0, 127 (0=off, 1-127=on)
63 MIDI Clock Off/On 0, 127 (0=off, 1-127=on)
100 Expression Pedal 0-127 (0=heel, 127=toe)
102 Bypass/On 0, 127 (0=bypass, 1-127=on)
NOTE: All on/off parameters are implemented with 0=off and any other
value (1-127)=on� They are documented as “0” and “127” because many MIDI
controllers send out 0 and 127 for on/off switches�
NOTE: Some MIDI applications and controllers start their MIDI enumeration
with 1 instead of 0� In these setups, increment the numbers above by one�
