pg 4
blueSky - reverberator
Knobs and Switches
Front Panel Controls
ON
Engages and bypasses the reverb effect� RED LED on indi-
cates that the effect is engaged� Bypass mode is true bypass
by default� (See page 10 for details�)
MIX
Controls the reverb mix from full dry at
minimum to full wet with no dry signal at
maximum� A 50/50 mix occurs at approxi-
mately 3 o’clock on the knob�
HIGH
Controls the amount of high frequencies
within the reverb signal� Select a damped
high end at minimum and no damping at
maximum
�
SHIMMER
Embellishes the reverb with an added pitch
shifting effect, which varies per the VERB
type in use:
• plate: adds regenerative octave-up pitch
shifting
• room: adds an octave plus a fifth
• spring: adds an octave-down pitch effect
with a pulsing tremolo applied� The
tremolo speed increases as you turn
past 12 o’clock
MOD
Select between light, deep, or no modulation�
