Sunset - Dual Overdrive
®
pg 4
Rear Panel
• POWER
Use an adapter with the
following rating: 9VDC center
negative. 250mA minimum.
• BRIGHT switch
Tailors the highest frequencies of the
output signal. Try the middle for a
balanced sound with most setups. Try
minus (-) for a smooth top end. Try plus (+)
to cut through with a warm amp/speaker
setup.
• FAV IN
Connect a MiniSwitch to remotely toggle a Favorite
preset. (See page 6 for more info.)
• EXP
Can be used in one of two ways with a standard TRS
expression pedal:
Expression Pedal Mode – Allows continuous control
over any of the knobs (See page 9 for more info).
Volume Mode – Allows control of the output volume
of the effect. (See page 10 for more info).
• IN
Mono instrument input.
• OUT
Mono signal output.
• CONFIG switch
Selects the effect order for the 2 sides
of Sunset. Selecting A+B will place the
effects in a parallel signal chain.
