-15-
WARNINGS:
 A residual current device having rated current not exceeding 30 mA
MUST be installed in the supply circuit.
 Isolate power supply before putting your hands in the liquid.
 The pressure control module must be protected from the elements.
Wiring (Surface models except Jet range)
The Wires in the mains lead (supply cord) are coloured in accordance with the following
code:
Green and Yellow: Earth Blue: Neutral Brown: Live
As colours of the core in the new mains lead may not correspond with the coloured
markings identifying the terminals in your connection unit, proceed as follows:
The wire which is coloured Green and yellow must be connected to the terminal marked
with the letter 'E' or by the earth symbol or coloured green or green and yellow.
The wire which is coloured Blue must be connected to the terminal marked with the
letter 'N' or coloured black.
The wire which is coloured Brown must be connected to the terminal marked with the
letter 'L' or coloured red.
Wiring (Jet range)
The moulded plug fitted to this appliance is not waterproof - keep dry.
The supply cord is factory fitted with a moulded plug incorporating a fuse, the value of
which is indicated on the pin face of the plug. Should the fuse need to be replaced, an
ASTA approved BS 1362 fuse must be used of the same rating, marked thus, . If
the fuse cover is detachable, never use the plug with the cover omitted. If a replacement
fuse cover is required, ensure it is of the same colour as that visible on the pin face of the
plug (i.e. red or orange).
If the plug supplied is not suitable for your socket outlet, it should be cut off and
destroyed.
WARNING: A plug with bared flexible cords is hazardous if engaged in a
live socket outlet.
The end of the flexible cord should be suitably prepared and correct plug fitted, as
follows:
The wires in this mains lead (supply cord) are coloured in accordance with the following
code:
Green & Yellow: Earth Blue: Neutral Brown: Live
As these colours may not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured green and yellow must be connected to the terminal in the
plug which is marked with the letter 'E' or by the earth symbol or coloured green or
green and yellow.
The wire which is coloured Blue must be connected to the terminal which is marked
with the letter 'N' or coloured black or blue.
The wire which is coloured brown must be connected to the terminal which is marked
with the letter 'L' or coloured brown or red.
