Stuart Turner BOOSTAMATIC 330 - Limits of Application

-4-
Notes:
N/A Denotes not applicable.
Submersible pumps must be fully submerged.
Max. permitted viscosity: 9.5 centistokes (Redwood No 1 scale).
Max. permitted ambient air temp: 40°C.
* With footvalve fitted.
** Max working pressure is the maximum pressure that can be applied to the pump
internal casing under any installation conditions.
*** The supply voltage must not exceed ±10% of the above listed
voltage.
eg. 230 ±10% or 110 ±10%
Failure to adhere will damage the unit.
LIMITS OF APPLICATION
Model Supply
(Note***)
Max.
Liquid
Temp.
°C
Min.
Liquid
Temp.
°C
Max.
Suction
Lift (m)
(Note*)
Max.
Immersion
Depth
(m)
Max. No.
Starts/h
Cut In
Pressure
(bar)
Cut Out
Flow
(l/min)
Max.
Working
Pressure
kPa (bar)
(Note**)
Max.
Inlet
Head
(m)
Max.
Head
(m)
(pump
closed
valve)
330 230/1/50 65 4 4.6 N/A 60 1.4 0.5 600 (6) 14 27
330 110/1/50 65 4 4.6 N/A 60 1.4 0.5 600 (6) 14 30.5
500 230/1/50 65 4 4.6 N/A 60 1.4 0.5 600 (6) 14 39.1
500 110/1/50 65 4 4.6 N/A 60 1.4 0.5 600 (6) 14 40
500 110/1/60 65 4 4.6 N/A 60 1.4 0.5 600 (6) 14 40.5
600 230/1/50 65 4 4.6 N/A 60 1.4 0.5 700 (7) 14 49.9
Diver 3 230/1/50 35 4 N/A 7 30 1.4 0.5 600 (6) N/A 34.8
Diver 4 230/1/50 35 4 N/A 7 30 1.4 0.5 600 (6) N/A 42.2
Jet 40 230/1/50 35 4 7 N/A 30 1.4 0.5 600 (6) 5 36.5
Jet 90 230/1/50 35 4 7 N/A 30 1.4 0.5 600 (6) 5 51
KB6 230/1/50 65 4 1.0 N/A 60 0.8 0.5 600 (6) 8 13.5
LB5-4 230/1/50 65 4 4.6 N/A 60 1.4 0.5 700 (7) 14 47.5
LB6-4 230/1/50 65 4 4.6 N/A 60 1.4 0.5 700 (7) 14 49.3
TB5-2 230/1/50 65 4 4.6 N/A 60 1.4 0.5 400 (4) 10 30.4
TB7-2 230/1/50 65 4 4.6 N/A 60 1.4 0.5 400 (4) 7 33
