Stuart Turner BOOSTAMATIC 330 - Table of Contents; Application

IMPORTANT NOTES
 Please read these instructions fully before starting the
installation:
 The installation must comply with the relevant water supply,
electrical and building regulations and be installed by a
competent person.
 If in doubt, consult Stuart Turner Ltd.
APPLICATION
The Boostamatic range is designed for pressure boosting applications in vented stored
*hot or cold, clean fresh water systems, where under gravity, no flow is available. Other
clean non aggressive, non explosive liquids with similar characteristics to water may be
pumped, consult Stuart Turner for such applications.
* Certain models only.
WARNING AGAINST MISUSE
 This pump set must not be used for any other application without the
written consent of Stuart Turner Limited and, in particular, must not be
connected directly to the mains water supply or used outside the
conditions specified in the limits of application.
 This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
-2-
BOOSTAMATIC MODELS
INDEX
. . . . . . . . . . . . . . . . . . . . . . . .Page No
Application . . . . . . . . . . . . . . . . . . . . . . . . . .2
Product Description . . . . . . . . . . . . . . . . . . .3
Limits of Application . . . . . . . . . . . . . . . . . . .4
Technical Specification . . . . . . . . . . . . . . . .5
Pump Connections . . . . . . . . . . . . . . . . . . .5/20
Pre Installation Assembly . . . . . . . . . . . . . .6
Siting of the Pump/Pipework . . . . . . . . . . . .6
Release & Connection of Push-in Fittings . .11
INDEX . . . . . . . . . . . . . . . . . . . . . . . .Page No
Electrical Installation . . . . . . . . . . . . . . . . . .13
Noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Commissioning . . . . . . . . . . . . . . . . . . . . . .20
Maintenance . . . . . . . . . . . . . . . . . . . . . . . .23
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Trouble Shooting Guide . . . . . . . . . . . . . . . .25
Environment Protection . . . . . . . . . . . . . . . .26
Surface Models Submersible Models
330
500
600
Jet 40
Jet 90
Kennet KB6
Loddon LB5-4
Loddon LB6-4
Thame TB5-2
Thame TB7-2
Diver 3
Diver 4
