PRODUCT DESCRIPTION
Electric motor driven pump complete with automatic control module consisting of flow
switch, pressure switch, pressure vessel and electronic control.
Motor
Diver Range: Class 'B' insulation, continuously rated and encapsulated with a (304)
stainless steel casing.
Jet Range: Class ‘B’ insulation, totally enclosed fan ventilated cooling, continuously
rated.
All Other Ranges: Class ‘F’ insulation, totally enclosed fan ventilated cooling,
continuously rated (except 600, see technical section).
General: All motors are induction type, permanent capacitor, fitted with integral auto
resetting thermal overload protection and comply with BS5000 or IEC 34-1. Enclosure
ratings are given in the technical specification section.
Pump
All models are close coupled to motor.
330, 500 and 600 are of single stage, end suction, peripheral design.
Diver 3 and 4 Submersible pumps are of three and four stage, centrifugal design.
Jet 40 and 90 are of centrifugal, end suction design.
Kennet KB6 is of single stage, end suction, centrifugal design.
Loddon LB5-4 and LB6-4 are of 4 stage, end suction, centrifugal design.
Thame TB5-2 and Thame TB7-2 are of two stage, end suction, centrifugal design.
Standard pump materials of construction of major wetted parts are as follows:-
Control Module
All models use the solid state IP65 rated pressure control module, mounted remotely in
the case of the Diver units. The wetted materials of construction are brass, rubber and
nylon 66. All control modules (except Diver) are factory fitted with a mains supply cord.
Model Body Impeller Shaft
Mechanical
Seal
330, 500, 600 Brass Brass Stainless Steel
Nitrile/Carbon
Ceramic/Stainless Steel
Jet 40 & 90 Polypropylene Noryl Stainless Steel
Nitrile/Carbon
Ceramic/Stainless Steel
Kennet KB 6 Brass Acetal Stainless Steel
Nitrile/Carbon
Ceramic/Stainless Steel
Loddon LB5-4,
LB6-4
Noryl
Stainless Steel
Polycarbonate Stainless Steel
Nitrile/Carbon
Sil Carbide/Stainless Steel
Thame TB5-2,
TB7-2
Noryl
Stainless Steel
Polycarbonate Stainless Steel
Nitrile/Carbon/Silicon
Carbide/Stainless Steel
Diver 3 & 4 Polypropylene Noryl
Stainless Steel
& Ceramic Sleeve
Lip Seal
