D19 MicVALVE
E2/8 Operation Date printed: 9.2.2000
Universal studio tool with
analog and digital outputs
(digital MCH output optional)
Mic/Line input unit for a digital
mixing console or a digital
routing matrix
Valve-dignified sound using the
Insert feature, simultaneously
converting a second analog
audio path to digital
AES/EBU and
TDIF 8-CH (optional) or
Optical 8-CH (optional)
D19 MicVALVE
MIC LINE
Studer
Mixing
Console
LINE (analog)
D19 MicVALVE
Studer
Digital Mixing
Console
AES / EBU
MIC LINE
Mic In
VALVE
Insert POST analog out
INSERT SEND
MIC
INSERT RETURN
AES/EBU and
TDIF 8-CH (optional) or
Optical 8-CH (optional)
D19 MicVALVE
LINE
(analog)
Insert Return
A/D Converter
AES/EBU or 8-CH out + Line out
