Curve (3) in the diagram below shows the 16-bit signal after Noise shaping
had been applied. The curve (4) is the same with only Dither applied.
More information on Noise shaping and Dithering technology is available at
your nearest Studer representative.
(4)
(3)
D19 MicVALVE
-150.0
-140.0
-130.0
-120.0
-110.0
-100.0
-90.00
20 100 1k 10k 20k
AMP1(dB
FS
) vs FREQ(Hz) & SWI(#)
