Quick guide RCC-02/-03
Quick guide V 6.1.0 19
Level
Nr
VarioTrack parameter description
Factory value
Expert
10033
Time period under voltage level 2 to start a new cycle
2 min
Expert
10034
Cycling restricted
Yes
Expert
10035
Minimal delay between cycles
1 hours
Expert
10038
SYSTEM
Expert
10054
Block manual programming (dip-switch)
No
Expert
10060
Check Earthing
No control
Inst.
10087
Disabling of the display button
No
Expert
10312
Remote entry (Remote ON/OFF)
Expert
10313
Remote entry active
Open
Expert
10314
ON/OFF command
No
Expert
10315
Activated by AUX1 state
No
Expert
10316
Start equalization
No
Expert
10317
Send a message when remote entry changes state
No
Expert
10335
Partial shading check
No
Expert
10336
Time between checks
5 min
Inst.
10342
VarioTrack watchdog enabled (SCOM)
No
Inst.
10343
VarioTrack watchdog delay (SCOM)
60 sec
Expert
10200
Reset PV energy meter
-
Expert
10043
Reset daily solar production meters
-
Expert
10044
Reset daily min-max
-
Basic
10056
Restore default settings
-
Inst.
10057
Restore factory settings
-
Inst.
10058
Parameters saved in flash memory
Yes
Expert
10039
ON of the VarioTrack
-
Expert
10040
OFF of the VarioTrack
-
Expert
10051
Reset of all VarioTrack
-
Expert
10088
AUXILIARY CONTACT 1
Expert
10089
Operating mode (AUX 1)
Automatic
Expert
10090
Combination of the events for the auxiliary contact (AUX 1)
Any (Function OR)
Expert
10092
Contact activated in night mode (AUX 1)
Expert
10093
Activated in night mode (AUX 1)
No
Expert
10094
Delay of activation after entering night mode (AUX 1)
1 min
Expert
10095
Activation time for the auxiliary relay in night mode (AUX 1)
1 min
Expert
10318
Contact active with a fixed time schedule (AUX 1)
Expert
10319
Contact activated with fixed time schedule (AUX 1)
No
Expert
10320
Start hour (AUX 1)
07:00 hh:mm
Expert
10321
End hour (AUX 1)
20:00 hh:mm
Expert
10096
Contact active on event (AUX 1)
Expert
10198
VarioTrack is ON (AUX 1)
No
Expert
10091
VarioTrack is OFF (AUX 1)
No
Expert
10308
Remote entry (AUX 1)
No
Expert
10097
Battery undervoltage (AUX 1)
No
Expert
10334
Battery undervoltage
10/20/40 Vdc
Expert
10098
Battery overvoltage (AUX 1)
No
Expert
10099
Earth fault (AUX 1)
No
Expert
10100
PV error (48h without charge) (AUX 1)
No
Expert
10102
Overtemperature (AUX 1)
No
Expert
10104
Bulk charge phase (AUX 1)
No
