Quick guide RCC-02/-03
Quick guide V 6.1.0 23
Level
Nr
VarioString parameter description
Factory value
Expert
14034
Minimal delay between cycles
1 hours
Expert
14037
SYSTEM
Expert
14174
Block manual programming (dip-switch)
No
Expert
14040
Type of battery grounding
No control
Expert
14194
Configuration for VS-120
Expert
14041
Type of PV grounding
No control
Expert
14175
Type of PV1 grounding
No control
Expert
14042
Type of PV2 grounding
No control
Expert
14180
Type of MPPT algorithm
Expert
14043
Type of MPP tracking algorithm PV
LSF
Expert
14044
PV voltage fixed (for PV in series)
700 Vdc
Expert
14179
PV voltage fixed (for PV in //)
500 Vdc
Expert
14045
Ratio of PV open circuit voltage
0.7
Expert
14176
Type of MPP tracking algorithm PV1
LSF
Expert
14177
PV1 voltage fixed
500 Vdc
Expert
14178
Ratio of PV1 open circuit voltage
0.7
Expert
14046
Type of MPP tracking algorithm PV2
LSF
Expert
14047
PV2 voltage fixed
500 Vdc
Expert
14048
Ratio of PV2 open circuit voltage
0.7
Inst.
14192
Establishment time (Algo MPPT)
0 sec
Inst.
14193
Averaging time (algo MPPT)
0 sec
Inst.
14190
PV wiring type erased from memory
-
Expert
14195
Configuration for VS-70
Expert
14196
Type of PV grounding
No control
Expert
14180
Type of MPPT algorithm
Expert
14197
Type of MPP tracking algorithm PV
LSF
Expert
14198
PV voltage fixed
500 Vdc
Expert
14199
Ratio of PV open circuit voltage
0.7
Inst.
14192
Establishment time (Algo MPPT)
0 sec
Inst.
14193
Averaging time (algo MPPT)
0 sec
Expert
14200
Remote entry (Remote ON/OFF)
Expert
14201
Remote entry active
Open
Expert
14202
ON/OFF command
No
Expert
14203
Activated by AUX1 state
No
Expert
14204
Start equalization
No
Expert
14205
Send a message when remote entry changes state
No
Inst.
14218
VarioString watchdog enabled (SCOM)
No
Inst.
14219
VarioString watchdog delay (SCOM)
60 sec
Expert
14182
Reset PV energy meter
-
Expert
14051
Reset daily solar production meters
-
Expert
14052
Reset daily min-max
-
Basic
14067
Restore default settings
-
Inst.
14068
Restore factory settings
-
Inst.
14069
Parameters saved in flash memory
Yes
Expert
14038
ON of the VarioString
-
Expert
14039
OFF of the VarioString
-
Expert
14059
Reset of all VarioString
-
Expert
14070
AUXILIARY CONTACT 1
