Studer RCC-02 Quick Guide

Studer Innotec SA
Quick guide RCC-02/-03
32 V 6.1.0 Quick guide
Nr
Message
Troubleshoot
6
Warning (006): Input voltage AC-In
too high
The AC-In source has exceeded the max AC
voltage {1432} during 600ms.
7
Warning (007): Input voltage AC-In
too low
The AC-In source is lost or close to the set limits
defined by {1200} or {1199} / {1198}.
8
Halted (008): Inverter overload SC
There has been a short-circuit or a connection of
too many loads. Control the connected loads
and verify that there has been no short-circuit
before restarting the device.
9
Halted (009): Charger short circuit
The power required for the loads connected to
AC-Out is too high. Perhaps a load that is too
powerful for the system has been connected or
there is a short-circuit in the AC-Out of the
Xtender. Inspect which loads are present and
verify the absence of a short-circuit before
restarting the device.
11
Warning (011): AC-In Energy quota
The daily AC-In energy quota has been reached
{1559}. Tomorrow it will be possible to consume
the same quantity of energy.
12
(012): Use of battery temperature
sensor
Indicates the presence of a BTS-01 temperature probe
connected to the device that sent the message.
14
Halted (014): Over temperature EL
XT: The max internal electronics temperature has
been reached. Confirm the ventilation air inputs
and outputs are not obstructed. Confirm the fans
are working properly (the device performs a fan
test when it is connected to the battery and you
can hear the fans spin during a few seconds while
turning on.
VT:VS: The device is stopped after surpassing the
max internal electronics temperature.
15
Halted (015): Inverter overload BL
The power required by the loads in inverter mode
is too large. The power of the connected loads is
greater than what the Xtender (Pnom, P30) can
provide. The RCC-02 shows the power delivered
by the device.
16
Warning (016): Fan error detected
XT: Check the proper functioning of the
ventilation fans during the start-up test of the
Xtender (power on). Make sure there is nothing
obstructing the fan blades and that they are
clean. If the error persists, please contact your
supplier.
VT:VS: The external ventilation module (ECF-01) is
defective or has been disconnected during the
functioning of the device.
18
Warning (018): Excessive battery
voltage ripple
Check the battery cable sections, their tightening
and their length.
