Pos. Denomination Description Comments
46 AC out
Light indicator
showing the
presence of a
voltage at the
output
This indicator is glowing continuously when an
alternative voltage of 230V is present at the device
output. It flashes when the device is in “load search”
mode due to the absence of users. (See chapter
6.2.2 – p. 20)
47
Stop acoustic
alarm
This button is not present on XTH.
Note: The acoustic alarm duration {15656} is factory
set at 0 sec. and is so deactivated.
16 MODEL IDENTIFICATION (FIG. 1B)
Pos. Denomination Description Comments
31 Model Model
32 Pnom/P30 Rated power output / power for 30 minutes
33 U Battery Rated battery voltage (input area) See chapter 6.2.8– p. 24
34 U ACin
Rated AC input voltage (input area) See chapter 6.2.3 – p.
20
35 I ACin/out
Maximum current at input / output See chapter 6.2.6 - p.
23.
36 U ACout Rated output voltage Or according to {1286}
37 I Charge
Maximum charger current See chapter 6.2.4 - p.
21
38 SN:xxxxxxxxxx Serial no.
39 IPxx Protection degree according to IEC 60529
