/11.2015/G17D
31
C
EN
Connect the condensate water drains to the local waste water system.
Comply with the regulations of the local water supply authority.
- Drop the plate slantwise on the frame of the fan unit (C).
- Push the plate upwards at the side which points towards the condensate pipe.
- Screw the connection piece into the condensate pipe and fix the syphon.
- Push the cone support plate into the rear latching.
- Retighten the screws to attach the cone support plate.
