Stulz ASR 682 A2 - Page 33

/11.2015/G17D
33
3
4
1
2
1
3
4
EN
Size 2
Size 3
fan power cable connection and
distribution for fan power lines
Legend:
1 - fan control cable connection
2 - fan power cable connection
3 - reheat control cable connection
4 - reheat power cable connection
