Stulz ASR 682 A2 - Page 34

34
/11.2015/G17D
3
4
4 3
1
1
EN
Size 4
Size 5
fan power cable connection and
distribution for fan power lines
fan power cable connection and
distribution for fan power lines
Legend:
1 - fan control cable connection
2 - fan power cable connection
3 - reheat control cable connection
4 - reheat power cable connection
