9. Bus communication on the EC tower
9.1 System examples with the C7000 Advanced
Minimum configuration
Maximum configuration (concerning the operational possibilities and the number of units)
The maximum configuration, in terms of operational possibilities and the number of units, consists of 10 units with an I/O controller
and C7000 Advanced, which also results in a total of 20 bus participants.
The minimum configuration consists of one unit with C7000 Advanced and I/O controller.
RS-485 I/O bus
C7000 Advanced
C7000 AdvancedC7000 Advanced
total:
10 units with IOC and
C7000 Advanced
