Stulz UltraWater 120 basic - Technical Data; Application Limits

STULZ UltraWater 3-stage reverse osmosis system SUW Transport / storage
© STULZ GmbH, Hamburg
-
17
-
6.4. Technical data
Model SUW 120 basic SUW 400 basic
Permeation rate
3)
12 l/h
1)
288 l/d 40 l/h
1)
960 l/d
Retention rate 95%
1)
95%
1)
Waste water/pure water ratio 1:1
1)
1:1
1)
Operating temperature 4…30°C 4…30°C
Ambient temperature 5…35°C 5…35°C
Intake pressure 1 - 5 bar 1 - 5 bar
Operating pressure Max. 4 bar Max. 4 bar
Water connections 6 mm 6 mm
Electrical connection 230 V, 50Hz 230 V, 50Hz
Nominal current 0.1 A 0.5 A
Protection class II II
Protection rating IP54 IP54
Pressure tank volume (total) 11 l 11 l
Minimum  lter service life (depending on untreated water)
2)
Approx. 6 - 12 months Approx. 3 - 6 months
Max. operating pressure of pressure tank 3 bar 3 bar
Minimum membrane service life (depending on untreated water) Approx. 2 years Approx. 2 years
Device dimensions (WxHxD) (580 x 410 x 150) mm (580 x 410 x 150) mm
Pressure tank dimensions (DixH) (240 x 360) mm (240 x 360) mm
Empty weight of device 9.3 kg 9.9 kg
Empty weight of pressure tank 2.4 kg 2.4 kg
1)
With salt content 500 mg/l, 4 bar, water temperature +15°C, no back pressure. At a lower water temperature, the permeation rate declines.
2)
With concentrations > 0.1 mg/l of free chlorine in the drinking water, the service life of the pre lter must be halved.
3)
The system produces up to 40% less pure water that the nominal  gure in winter, but up to 60% more in the summer.
6.5. Application limits
Maximum untreated water temperature +35°C
Maximum untreated water conductivity 400 μS/cm
Maximum untreated water hardness 15°dH
Maximum Silt Density Index SDI SDI <3
Iron concentration < 0.1 mg/l
Manganese concentration < 0.05 mg/l
Microbiological requirement acc. to TrinkwV
Drinking water as per local Drinking Water Regulations!
